Passenger Elevator Series
Reliable Vertical Transportation for Residential and Commercial Buildings
Relivo Passenger Elevators are designed to provide safe, smooth, and efficient vertical transportation in residential apartments, commercial buildings, offices, hospitals, and public
infrastructure. Built with advanced technology and robust engineering, these elevators ensure high performance, passenger comfort, and long-term reliability.
The passenger elevator series from Relivo Elevators Private Limited combines modern control systems, energy-efficient drives, and premium cabin designs to meet the requirements of modern buildings.
- Key Features
Smooth and Comfortable Ride
Advanced VVVF drive technology ensures smooth acceleration and deceleration, providing a comfortable ride for passengers.
Energy Efficient Operation
Modern drive systems reduce power consumption and improve operational efficiency.
Elegant Cabin Design
Multiple interior design options allow the elevator cabin to match the building architecture.
Intelligent Control System
Microprocessor-based controllers manage elevator movement with high precision and reliability.
Advanced Safety Technology
Multiple safety systems ensure safe operation under all conditions.
Technical Specifications
General Specifications
| Parameter | Specification |
|---|---|
|
Elevator Type |
Passenger Elevator |
|
Capacity |
4 – 26 Persons |
|
Load Capacity |
272 kg – 2000 kg |
|
Speed Options |
0.5 m/s – 2.5 m/s |
|
Maximum Floors |
Up to 40 Floors |
|
Maximum Travel Height |
Up to 120 meters |
|
Leveling Accuracy |
±5 mm |
|
Operation |
Collective Selective Automatic |
Mechanical Specifications
| Component | Specification |
|---|---|
|
Drive System |
Gearless / Geared Traction Drive |
|
Machine Type |
Machine Room Less (MRL) / Machine Room Type |
|
Traction System |
Steel Wire Rope Traction |
|
Counterweight |
Structural Steel Frame with Cast Iron Blocks |
|
Guide Rails |
T-Type Precision Guide Rails |
|
Suspension Ratio |
1:1 or 2:1 |
Electrical Specifications
| Parameter | Specification |
|---|---|
|
Controller |
Microprocessor Based Elevator Controller |
|
Drive Type |
VVVF AC Drive |
|
Power Supply |
415V ±10%, 3 Phase, 50 Hz |
|
Control Voltage |
24V DC |
|
Cabin Operating Panel |
Stainless Steel COP with LED Indicators |
|
Landing Operating Panel |
Micro Touch Buttons |
|
Display |
LED / LCD Floor Display |
Door System
| Parameter | Specification |
|---|---|
|
Door Type |
Automatic Center Opening / Telescopic |
|
Door Drive |
VVVF Door Operator |
|
Door Width |
700 mm – 1200 mm |
|
Door Height |
2000 mm – 2100 mm |
|
Door Protection |
Infrared Safety Curtain / Light Curtain |
Safety Systems
Relivo passenger elevators include advanced safety systems:
• Automatic Rescue Device (ARD)
• Overload Protection System
• Door Interlock Safety System
• Overspeed Governor
• Emergency Alarm
• Emergency Stop Switch
• Intercom System
• Safety Gear Mechanism
• Upper and Lower Terminal Limits
• Oil Buffer / Spring Buffer
All elevators comply with IS elevator safety standards and international safety guidelines.
Cabin Interior Options
Passenger elevator cabins are available in multiple design finishes.
Wall Finish Options
- Mirror Stainless Steel
- Hairline Stainless Steel
- Decorative Laminates
- Designer Panels
- Glass Panels
Flooring Options
- Granite
- Marble
- PVC Flooring
- Artificial Stone
Ceiling Options
- LED Decorative Ceiling
- Stainless Steel Ceiling
- Designer Lighting Panels
Handrail Options
- Stainless Steel Handrail
- Designer Handrail
Applications
Relivo Passenger Elevators are suitable for:
- Residential Apartments
- Office Buildings
- Shopping Complexes
- Hospitals
- Hotels
- Educational Institutions
- Public Buildings
Why Choose Relivo Elevators
Why Choose Relivo Passenger Elevators
- Smooth and silent ride
- Energy efficient operation
- Advanced safety systems
- Elegant cabin interiors
- Reliable control technology
- Custom design options
- Professional installation and service
- Quotation Request
Request a Project Quotation
For quotation and project consultation please provide:
