Service Elevator Series
Reliable Lifts for Efficient Building Operations
The Relivo Service Elevator Series is designed for efficient transportation of service staff, maintenance equipment, housekeeping materials, and supplies within buildings. These elevators are idely used in hotels, hospitals, restaurants, shopping malls, and commercial complexes where dedicated service lifts are required to separate service movement from passenger traffic.
Built with durable construction, efficient drive systems, and advanced safety mechanisms, Relivo service lifts ensure smooth operation and reliable performance even under frequent usage.
- Key Features
Efficient Material Transport
Designed to carry housekeeping carts, maintenance equipment, cleaning supplies, and service materials.
Durable Cabin Construction
Robust steel cabin structure designed for long-term heavy usage.
Smooth and Stable Operation
Advanced VVVF drive system ensures controlled acceleration and smooth ride quality.
Compact and Practical Design
Optimized cabin dimensions suitable for service areas and back-of-house operations.
Reliable Performance
Built for continuous operation in high-demand environments.
Technical Specifications
General Specifications
| Parameter | Specification |
|---|---|
|
Elevator Type |
Service Elevator |
|
Capacity |
500 kg – 2000 kg |
|
Speed Options |
0.5 m/s – 1.5 m/s |
|
Maximum Floors |
Up to 30 Floors |
|
Maximum Travel |
Height Up to 90 meters |
|
Operation |
Automatic / Attendant Operation |
|
Leveling Accuracy |
±5 mm |
Mechanical Specifications
| Component | Specification |
|---|---|
|
Drive System |
Geared / Gearless Traction Machine |
|
Machine Type |
Machine Room / MRL |
|
Traction System |
Steel Wire Rope Traction |
|
Counterweight |
Steel Frame with Cast Iron Blocks |
|
Guide Rails |
High Precision T-Type Guide Rails |
|
Cabin Structure |
Reinforced Steel Frame |
Electrical Specifications
| Parameter | Specification |
|---|---|
|
Controller |
Microprocessor Based Intelligent Controller |
|
Drive Type |
VVVF AC Drive |
|
Power Supply |
415V ±10%, 3 Phase, 50 Hz |
|
Control Voltage |
24V DC |
|
Cabin Operating Panel |
Stainless Steel COP |
|
Landing Operating Panel |
Micro Touch Buttons |
|
Landing Operating Panel |
Industrial Push Buttons |
|
Display |
LED Floor Indicator |
Door System
| Parameter | Specification |
|---|---|
|
Door Type |
Automatic Center Opening / Telescopic |
|
Door Drive |
VVVF Door Operator |
|
Door Width |
900 mm – 1400 mm |
|
Door Height |
2000 mm – 2100 mm |
|
Door Safety |
Infrared Light Curtain |
Wide door openings allow easy movement of service carts and equipment.
Cabin Specifications
| Component | Specification |
|---|---|
|
Cabin Structure |
Stainless Steel / Mild Steel |
|
Cabin Wall Finish |
Anti-Skid Chequered Plate / PVC |
|
Ceiling |
Industrial LED Lighting |
|
Handrails |
Stainless Steel Handrails |
|
Cabin Finish |
Durable Industrial Finish |
Safety Systems
Relivo service elevators include advanced safety systems:
• Automatic Rescue Device (ARD)
• Overload Protection System
• Door Interlock Safety
• Overspeed Governor
• Emergency Alarm
• Intercom Communication System
• Emergency Stop Switch
• Terminal Limit Switches
• Safety Gear Mechanism
• Oil Buffers
All elevators comply with elevator safety regulations and industrial safety standards.
Applications
Relivo Service Elevators are ideal for:
• Hotels
• Hospitals
• Restaurants
• Shopping Malls
• Office Buildings
• Commercial Complexes
• Industrial Buildings
Benefits of Service Elevators
• Efficient transportation of service materials
• Reduced congestion in passenger elevators
• Improved operational efficiency
• Safe movement of service equipment
• Durable design for heavy usage
Why Choose Relivo Service Elevators
• Durable construction for heavy-duty use
• Smooth and reliable operation
• Advanced safety features
• Efficient service transportation
• Customizable cabin dimensions
• Professional installation and maintenance
- Quotation Request
Request a Project Quotation
Planning to install a service elevator for your building? Our engineers will assist you with the correct configuration.
Please provide the following details:
